Self-supporting PENTA W. roof panel with rockwool insulation, used for industrial and commercial flat or low slope roofs. The double sheet panel has glued on the dogato flat side a pvc or polyolefin synthetic membrane. In the building site it is necessary make the hot welding between the joint to obtain a waterproofing roof.
The weldings have to be made by specialized people.
5 ribs, ribs’ height 40 mm, ribs’ breath 250 mm
Dogato external side:dogato steel support with glue a pvc or polyolefin synthetic membran
Ribbed internal side: steel support
Working width: 1.000 mm
Thicknesses (mm): 50-60-80-100-120-150-200
